RFID industrial printer

Printing method

Direct thermal & Thermal transfer

Resolution

300 DPI(11.8dots/mm)

Maximum print speed

8 IPS(203.2mm/s)

Maximum print width

4.15″ (105.6mm)

Maximum print length

78.7″(2000mm)

Memory

32 MB Flash ROM, 16 MB SDRAM

Media

Roll-feed, die-cut, continuous, fan-fold, tags, tickets in plain paper or thermal paper
Width：4.6″(118mm) max., 0.8″(20mm)min.
Supply roll: OD 8″(203.2mm) max., ID 1″(25.4mm) min.
Thickness: 0.06～1.5mm(0.002″～0.06″), including liner,  support flexible on-metal tag.

Ribbon

Wax, Wax/Resin, Resin
Ribbon roll: OD 2.75″(70mm) max. with ID 1″(25.4mm) core or ID 0.5″(12.7mm) core
Max width: 110mm; Max length: 300M

Media sensor

Adjustable reflective & Transmissive

RFID function(option)

UHF: High performance RFID reader/encoder, supports various labels compatible with EPC Gen 2/ISO 18000-6C.

or

HF: Support ISO/IEC 15693/14443A/NFC/UltraLight protocol, support write ASCII, hexadecimal, NDEF format text or URL address, support tag encryption and locking.

Barcode Types

1D Barcode : Code 39，Code 93，Code 128，Codabar，EAN-8/13/128，Interleave
2 of 5，UCC-128，UPC A/E 2 and 5 add-on, etc.
2D Barcode : Data Matrix, MaxiCode, PDF417,QR, etc.

Interfaces

USB, LAN

Input Key

Five Input Key

LED

Three LED indicator lights

Display

4.3 "IPS touch screen (480X800)

Power Supply

85 ~ 264 VAC，47 ~ 63Hz，150W

Weight

12.5 KGS

Dimensions

W299 x D410 x H270 mm

Operation
environment

Temperature: 32° F ~ +104° F (0° C ~ 40° C)
Relative humidity: 5% - 85% non condensing

Storage environment

Temperature: -40° F ~ +140° F (-40° C ~ 60° C)
Relative humidity: 5% - 85% non condensing

Options

Peeler, UHF module, HF module, Bluetooth module(Non RFID Printer)
